Basic Info.

Model NO.	TGGS
Feature	Corrosion Resistant, Oxidation Resistance, Chemical Stability, Wear-resistant
Material	HDPE
Keyword	Soil Stabilization Geocell Grid
Surface	Textured Smooth
Height	50mm~250mm
Welding Distance	330mm-1000mm
Thickness(Textured)	1.1-1.8mm
Transport Package	Container
Specification	Cell depth: 50mm, 100mm, 150mm, 200mm, 250mm
Trademark	zhongloo
Origin	China
HS Code	3920109090
Production Capacity	30000m2/Day

Product Description

1.1-1.8mm Textured/Perforated HDPE Plastic Sheet Cellular Geocells for Channel Slopes Reinforcement Protection

HDPE plastic honeycomb hdpe geocell gravel grid basic details:1.Cell depth: 50mm ,100mm , 150mm , 200mm , 250mm 2. Welding space: 330mm ~ 1600mm 3. Thickness:(1)1.0mm~1.2mm for smooth geocell(2) 1.5mm~1.7mm for textured geocell
HDPE plastic honeycomb hdpe geocell gravel grid Introduction:Plastic geocell cellular confinement system is three dimensional , honeycomb like structures manufactured from high density polyethylene and jointly welded by ultrasonic technique . It is flexible to fold during the transport and installation on construction site . The geocell nets will be filled with soils , granular, cements or other on-site infill materials when stretched into web structures , which has powerful and rigid confinement in the lateral and vertical sides .
HDPE plastic honeycomb hdpe geocell gravel grid Features:1) Light material , resistant to wear , stable in chemical properties , anti-aging , resistant to acids and alkalis, applicable to different soil and desert and other geological conditions .2)High limit on lateral direction , anti-skidding , anti-deformation , effectively enhance the supporting ability and scattered load function of roadbed .3)High carrying capacity and good dynamic performance and high erosion ability .4)The geometry size can be changed to meet different needs of the project , such as height and welding distance .5)Retractable and small loading volume , convenient joint , speed construction .6)Local material can be used during construction , reduce the construction cost , easy to be transported after folding together .
Technical Parameters:

Material Properties	Unit						Test Method
Cell Depth	mm	75	100	150		200
Polymer Density	g/cm3	0.935-0.965					ASTM D 1505
Environmental Stress Crack Resistance	Hours	>400					ASTM D 5397
Environmental Stress Crack Resistance	Hours	6000					ASTM D 1693
Carbon Black Content	%	1.5% - 2.0%					ASTM D 1603
Nominal Sheet Thickness Before Texturing	mm	1.27 -5%,+10%					ASTM D 5199
Nominal Sheet Thickness After Texturing	mm	1.52-5%,+10%					ASTM D 5199
Strip Puncture Resistance	N	450					ASTM D 4833
Seam Peel Strength	N	1065	1420	2130	2840		EN ISO13426-1B
Seam Efficiency	%	100					GRI-GS13
Nominal Expanded Cell Size (width x length)	mm	320x287,475x508 etc
Nominal Expanded Panel Size (width x length)	m	2.56x8.35, 4.5x5.0, 6.5x4.5, 6.1x2.44

Applications:Plastic geocell grid gravel for road
1. Used for all kinds of road building , driveways , soil stabilization and embankment stabilization2. Used to stabilize river embankments .3. Used to prevent landslides . 4. Using Geocell construction can greatly reduce labor intensity and reduce the thickness of the roadbed , construction speed , good performance and greatly reduce the project cost .
